LED Lane Controls
THE BEST QUALITY SIGNAL YOU CAN GET. LONG LASTING AND RUGGED.
Lane Control Signals are designed to maintain efficient traffic flow. These signals are used to indicate toll booth lanes open or closed, direct vehicles out of closed lanes in tunnels, and manage traffic flow in changeable lanes.
The signal is available in an 8" or 12" round lens module in a waterproof polycarbonate housing. The signal displays a red X and a green arrow (with an optional yellow phase that may be set for flash or no-flash). Power consumption is less than 11 watts with a life of greater than 100,000 hours.
Circuits are built using "chains" of LED's to avoid catastrophic failure of the signals. Power supplies are discrete for each color and are regulated over a wide voltage range for consistent light output.
8" Lane Controls
| LC1-8A | Our 8" (200mm) LED lane control signal with a green arrow. |
|
| LC1-8X | Our 8" (200mm) LED lane control signal with a red X. |
|
| LC2-8 | Our 8" (200mm) LED lane control signal with a red X and a green arrow. |
|
| LC3-8 | Our 8" (200mm) LED lane control signal with a red X, green arrow, and yellow ball. |
|
12" Lane Controls
| LC1-12A | Our 12" (300mm) LED lane control signal with a green arrow. |
|
| LC1-12X | Our 12" (300mm) LED lane control signal with a red X. |
|
| LC2-12 | Our 12" (300mm) LED lane control signal with a red X and a green arrow. |
|
| LC3-12 | Our 12" (300mm) LED lane control signal with a red X, green arrow, and yellow ball. |
|
20" Lane Controls
| LC2-20 | Our 20" (500mm) LED lane control signal with a red X and a green arrow. |
|
| LC3-20 | Our 20" (500mm) LED lane control signal with a red X, green arrow, and yellow ball. |
|
- All signals are available in 120VAC as standard.
- Our ultrabright LEDs are rated for 100,000 hours of continuous operation at nominal current at 25°C.
- The operating temperature range is from -40°C to 74°C.
- The LED emission spectrum shall meet the present ITE chromaticity diagram according to the 1931 CIE standard.
- The viewing angle shall not be less than 30°.
- This heavy duty unit is designed to replace older halogen fiber optic units.
- Power consumption is less than 20 watts with a life greater than 100,000 hours continuous use.
- Operating costs are extremely low.
- Relamping, as in the quartz units, is not necessary.
- The aluminum housing is weatherproof and is powder coated black.
- Displays a red X, yellow X (optional) and a green arrow.
- Yellow may be set for flash or no-flash.
